Haas ST-35Y CNC Lathe

Stock #: 210260008

$74,500.00

See Product Details

Business Financing Available

  • Stock #: 210260008
  • Brand: Haas

Business Financing Available

  • Stock #: 210260008
  • Brand: Haas

Request Formal Quote

Fill out the form below to receive a quote on this machine. Once the form is filled out, you will be able to see all pricing throughout our website.

"*" indicates required fields

This field is for validation purposes and should be left unchanged.
Provide Shipping Quote
Provide Financing Options
This field is hidden when viewing the form
This field is hidden when viewing the form
This field is hidden when viewing the form
This field is hidden when viewing the form
This field is hidden when viewing the form
This field is hidden when viewing the form

Product Description

General Info

  • Stock #: 210260008
  • Location: Decatur, GA
  • Brand: Haas
  • Model: ST-35Y
  • Serial #: 3105526
  • Year: 2016
  • Approx. Shipping Weight: 15,000 Lbs.

Specifications

  • Swing Over Bed: 31.75″
  • Max Cutting Diameter: 12″
  • Max Cutting Length: 32.5″
  • Bar Capacity: 4″
  • Chuck Size: 12″
  • Spindle Nose: A2-8
  • Spindle Bore: 4.62″
  • Draw Tube Bore: 4.06″
  • Spindle Speed: 0 – 3,200 RPM
  • Spindle Torque: 425 ft-lb @ 325 RPM
  • Peak Horsepower: 40 HP
  • X-Axis Travel: 9.4″
  • Y-Axis Travel: 4.0″
  • Z-Axis Travel: 32.5″
  • Turret: 12 Station Hybrid BOT / VDI
  • Coolant Capacity: 55 Gallons
  • Electrical: 220V/3PH

Equipped With

Y-Axis Live Tooling, 12-Station Hybrid BOT / VDI Turret, Hydraulic Programmable Tailstock, Haas Next-Gen Color LCD Widescreen Control, Box Way Construction, Hennig Chip Conveyor, Loc-Line Coolant System, 40 HP Haas Vector Drive, Servo Amplifiers (X, Y, Z, C-Axis, Live Tooling, Spindle, Tool Turret, Tailstock, Bar Feeder, Auto Door), Wiper Kit (New – P/N 93-1994)

Additional Info

The Haas ST-35Y CNC Lathe can be demoed upon request. Check out the video on the listing to see it in operation.
