DoAll 3612-VH 36″ Hydraulic Table Feed Contour Vertical Band Saw
Stock #: 150240004
$19,500.00
Request Formal Quote
Fill out the form below to receive a quote on this machine. Once the form is filled out, you will be able to see all pricing throughout our website.
Product Description
General Info
- Stock #: 150240004
- Location: Stone Mountain, GA
- Brand: DoAll
- Model: 3612-VH
- Serial #: 570-11132
- Year: 2011
- Approx. Shipping Weight: 2,500 Lbs.
- Approx. Shipping Dimensions: 7′ L x 4′ W x 7′ H
- Skidding Fee: Skidding Unavailable
Specifications
- Machine Cutting Capacity: 36″ W x 12″ H
- Throat, Band to Column: 36″
- Maximum Work Height: 12″
- Band Speed: 30 – 5500 FPM
- Band Width Capacity: 1/8″ – 1″
- Band Length: 199″
- Table: 26-1/2″ x 33-1/2″ ; Tilts 45°R, 10°L
- Table Stroke: 12″
- Table Feed: 0 – 6 FPM
- Table Feed Force: 0 – 175 lbs.
- Table Capacity: 500 lbs.
- AC Motor Drive: 3HP
- Electrical: 460V/3PH
Equipped With
Variable Frequency Band Speed AC Drive, Dual-Range Transmission, Variable Hydraulic Table Feed, Band Tension Indicator, Removeable Chip Drawer, Adjustable Vise, Chip Blower, Instruction Manual
Additional Info
The DoAll Vertical Band Saw can be demoed upon request. Check out the video on the listing to see it in operation.
