AKYAPAK APK 81 3″ x 3″ x 3/8″ CNC Angle Roll (2020)
Stock #: 171250026
$37,500.00
Request Formal Quote
Fill out the form below to receive a quote on this machine. Once the form is filled out, you will be able to see all pricing throughout our website.
"*" indicates required fields
Product Description
General Info
- Stock #: 171250026
- Location: OK
- Brand: AKYAPAK
- Model: APK 81
- Year: 2020
- Approx. Shipping Weight: 3,500 LBS
- Approx. Shipping Dimensions: 4.5’L x 5.25’W x 6’H
- Loading Fee: Loading Included
Specifications
- Angle Iron – Leg Out: 3″ x 3″ x 3/8″ to 63″ ID
- Angle Iron – Leg In: 3″ x 3″ x 3/8″ to 78″ ID
- Flat Bar – On Flat: 4-3/4″ x 1-1/8″ to 82″ ID
- T-Bar: 3″ x 3″ x 5/16″ to 55″ ID
- Rectangular Bar: 4-13/16″ to 82″ ID
- Square Bar: 1-3/4″ to 40″ ID
- U-Bar Channel: 3/8″ x 5/16″ to 48″ ID
- Power: 6.8 HP
- Roll Diameter: 9.65″
- Shaft Diameter: 3.15″
- Bending Speed: 13 ft/min
- Voltage: 230 / 480V – 3Ph
Equipped With
Hydraulic side supports, Set of Standard Rolls Included, AKYAPAK AK-400 Control System
Additional Info
Machine is under power and available to demo.
