Tsugami VA2 High Speed Vertical Machining Center

Stock #: 121230008

$59,950.00

  • Stock #: 121230008
  • Brand: TSUGAMI
  • Stock #: 121230008
  • Brand: TSUGAMI

Request Formal Quote

Fill out the form below to receive a quote on this machine. Once the form is filled out, you will be able to see all pricing throughout our website.

  • Hidden
  • Hidden
  • Hidden
  • Hidden
  • Hidden
  • This field is for validation purposes and should be left unchanged.

Product Description

General Info

  • Stock #: 121230008
  • Location: GA
  • Brand: Tsugami
  • Model: VA2
  • Year: 2018
  • Loading Fee: Rigging Required

Specifications

  • Table size: 500 mm x 300 mm
  • Distance between spindle face and table face: 110 mm – 360 mm
  • Maximum weight on table: 200 kg (uniformed load)
  • X-axis stroke: 360 mm
  • Y-axis stroke: 260 mm
  • Z-axis stroke: 250 mm
  • Rapid traverse rate (X, Y, Z axis): 40 m/min
  • Cutting feed rate: 1 to 30,000 m /min
  • Spindle taper: 7/24 taper S20T
  • Spindle speeds: 7/24 taper S20T Spindle speeds 300 to 30,000 min-1 (Normal highest spindle speed 28,000 min-1)
  • Tool storage capacity: 14 tools (Maximum mountable tool number: 15 tools)
  • Maximum tool size (W x L): 60 mm x 130 mm

Equipped With

30,000 RPM Integral Spindle, 14 Position High Speed ATC, Tool Breakage Detection

Additional Info

Machine can be inspected upon request.

This machine is being sold from our client’s facility and is sold AS-IS (Not covered under the MDNA Return Privilege). We always recommend machine be inspected in person to verify condition.
