This item has been sold

Search our inventory for a comparable solution

Trumpf TruLaser 2030 10′ X 5′ Fiber Laser Gantry System Included!

Name: Trumpf TruLaser 2030 10' X 5' Fiber Laser Gantry System Included!
SKU: 195136
Price: 178500.00 USD
Availability: OutOfStock

Stock #: 181250027

$178,500.00

See Product Details

Out of stock

Stock #: 181250027
Brand:

Not What You're Looking For?

Have Surplus Machinery to Sell?

Out of stock

Stock #: 181250027
Brand:

Request Formal Quote

Fill out the form below to receive a quote on this machine. Once the form is filled out, you will be able to see all pricing throughout our website.

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

First Name*

Last Name*

Company Name*

Phone*

Email*

Street Address

City

State

Zip

Message

Provide Shipping Quote

Provide Financing Options

This field is hidden when viewing the form

Post ID

This field is hidden when viewing the form

Quantity

This field is hidden when viewing the form

Product Name

This field is hidden when viewing the form

Product URL

This field is hidden when viewing the form

Product Price

Product Description

General Info

Stock #: 181250027
Location: Columbus, Ohio
Brand: Trumpf
Model: TruLaser 2030
Year: 2018
Approx. Shipping Weight: 25,000-28,000 lbs
Approx. Shipping Dimensions: Length 28 Ft., Width: 22 Ft., Height: 7.5 Ft.
Loading Fee: Rigging Required

Specifications

Working Range: 120″ × 60″ (3,000 mm × 1,500 mm)
Laser Type: Solid-state fiber (TruDisk 4001)
Laser Power: 4,000 Watts (4 kW)
Maximum Sheet Thickness: Mild Steel: 1.0″ (25 mm), Stainless Steel: 0.80″ (20 mm), Aluminum: 0.80″ (20 mm), Brass: 0.31″ (8 mm) Copper: 0.31″ (8 mm)
Maximum Simultaneous Axis Speed: (5,512 in/min) 140 m/min
Positioning Accuracy: ±0.05 mm (±0.002″)
Average Power Consumption: 13 kW
Total Connected Load (Peak): 50-60 kVA
Voltage: 400/480V, 3-phase
Amperage: 75-100A full load
Phases: 3-phase

Equipped With

Full Gantry Automated Loading/Unloading System, Dual Shuttle Tables, Automatic Pallet Changer, Automatic Nozzle Changer, Single Cutting Head, Trumpf CNC Touchscreen Control, TruTops Boost Software, FlyCut High-Speed Piercing, PierceLine, CoolLine, Drop&Cut, DetectLine Focus Control, Nitrogen/Oxygen Cutting Capable, Integrated Dust Extraction Interface, External Chiller Included, Fully Enclosed Safety Cabin, Excellent Condition, 15681 Operating Hours, Under Power For Inspection
