Tarnow TUJ-50M 22″ x 80″ Engine Lathe
Stock #: 190240104
$8,500.00
Request Formal Quote
Fill out the form below to receive a quote on this machine. Once the form is filled out, you will be able to see all pricing throughout our website.
Product Description
General Info
- Stock #: 190240104
- Location: Stone Mountain, GA
- Brand: Tarnow
- Model: TUJ-50M
- Year: 1979
- Approx. Shipping Weight: 7,500 Lbs.
- Approx. Shipping Dimensions: 12′ L x 5′ W x 5′ H
- Skidding Fee: Skidding Unavailable
Specifications
- Swing Over Bed: 22″
- Distance Between Centers: 78.74″
- Swing Over Gap: 31.5″
- Number of Spindle Speeds: 18
- Range of Spindle Speeds: 20 – 1600 RPM
- Spindle Bore Diameter: 3.54″
- Range of Metric Threads (32): 0.25 – 28 mm
- Range of Inch Threads (49): 1 – 112 TPI
- Spindle Nose: D1-11
- Main Drive Motor Power: 14.75 HP
- Electrical: 230V/3PH
Equipped With
Operation Manual, Spare Parts Catalogue, Appendices, 3 Jaw Chuck, Steady Rest, Coolant Pump
Additional Info
The Tarnow Lathe can be demoed upon request, check out the video on the listing to see it in operation.
