South Bend SB1012F 14″ x 40″ Toolroom Lathe w/ Fagor DRO
Stock #: 130230030
$19,950.00
Request Formal Quote
Fill out the form below to receive a quote on this machine. Once the form is filled out, you will be able to see all pricing throughout our website.
Product Description
General Info
- Stock #: 130230030
- Location: Stone Mountain, GA
- Brand: South Bend
- Model: SB1012F
- Serial #: 0021
- Year: 2014
- Approx. Shipping Weight: 3,500 Lbs.
- Approx. Shipping Dimensions: 8′ L x 4′ W x 6′ H
- Skidding Fee: Skidding Unavailable
Specifications
- Swing Over Bed: 14.17″
- Distance Between Centers: 40″
- Swing Over Cross Slide: 8.375″
- Swing Over Gap: 20.98″
- Spindle Nose to Gap: 6.5″
- Cross Slide Travel: 9.25″
- Compound Travel: 5.1″
- Spindle Nose: D1-6 Camlock
- Spindle Bore: 2.0625″
- Spindle Taper: MT#6
- Tailstock Taper: MT#4
- Inch Threads: 2 – 72 TPI
- Metric Threads: 0.20 to 14mm
- Motor HP: 5
- Electrical: 220V/3PH
Equipped With
Fagor 2-Axis Digital Readout, South Bend SB1268 Collet Attachment with Collets, (2) Southbend Drawer Sets, Aloris Toolpost with Toolholders, South Bend 3 & 4 Jaw Chucks, Faceplate, Steady Rest, Follow Rest, Light, Coolant System, Chuck Guard
Additional Info
The South Bend Lathe can be demoed upon request. Check out the video on the listing to see it in operation.
