Skoda SRM 125/12-75 49″ x 480″ Heavy Duty Engine Lathe, 40′ Turning Length
Stock #: 180250032
$99,500.00
Request Formal Quote
Fill out the form below to receive a quote on this machine. Once the form is filled out, you will be able to see all pricing throughout our website.
"*" indicates required fields
Product Description
General Info
- Stock #: 180250032
- Location: Decatur, GA
- Brand: Skoda
- Model: SRM 125/12-75
- Serial #: 20 896
- Approx. Shipping Weight: 55,000 Lbs.
- Approx. Shipping Dimensions: 53′ L x 8′ W x 7′ H
Specifications
- Swing Over Bed: 49″
- Swing Over Carriage: 35″
- Distance Between Centers(Approximate): 480″
- Maximum Torque of Face plate: 22,780 ft.-lbs.
- Maximum Weight of Workpiece Between Centers(Without Rests): 30,850 Lbs.
- Height of Bed: 24-1/2″
- Width of Bed: 43-1/4″
- Spindle Speeds 1st Range: 1.8 to 90 1.4 to 71 RPM
- Spindle Speeds 2nd Range: 8 to 400 6,3 to 315 RPM
- Metric Threads(28): 1 to 50
- Module Threads(28): 2 to 20
- Whitworth Threads: 24 to 1/2 TPI
- Main Motor: 50 HP
- Motor For Rapid Traverse of Carriage: 1.75 HP
- Motor For Travel of Tailstock: 1.5 HP
- Overall Bed Length: 542″
- Electrical: 480V/3PH
Equipped With
(3) Steady Rest, Powered Tailstock, Powered Carriage Feed, Manuals/documentation
Additional Info
The Skoda Engine Lathe can be demoed upon request.
