Schulz 7580HV30X-3 7.5 HP Piston Air Compressor
Stock #: Schulz-7580HV30X-3
Request Formal Quote
Fill out the form below to receive a quote on this machine. Once the form is filled out, you will be able to see all pricing throughout our website.
"*" indicates required fields
Product Description
General Info
- Stock #: Schulz-7580HV30X-3
- Brand: Schulz
- Model: 7580HV30X-3
- Approx. Shipping Weight: 553 lbs. / 251 Kg
- Approx. Shipping Dimensions: 56″ x 23″ x 45″ / 1.42m x 0.58m x 1.14m
Specifications
- Motor Horsepower: 7.5 HP / 5.6 KW
- Voltage: 208-230/460 V / Three Phase
- Max Operating Pressure: 175 PSI / 12.07 bar
- Free Air Delivery @ 175 PSI: 21.6 CFM / 612 L/min
- Theoretical Displacement: 30 CFM / 849 L/min
- Number of Stages: 2
- Number of Pistons: 2-V
- Tank Capacity: 80 Gallons / 303 L
- Tank Type: Horizontal
- Lubrication: Oil-Lubricated
- Pump Material: Cast Iron
Equipped With
Standard Accessories: Cast iron construction, Low RPM two piston V design, Large metal intake filter/silencers, Magnetic starters mounted and wired, TEFC motors, Auto start/stop pressure switch operation, Powder coated ASME receivers, Enclosed metal belt guard, Easy access to adjust belt tension, Balanced drive pulleys, Oversized check valves, ASME safety relief valves, Pressure gauge, Manual condensate drain, Swedish stainless steel reed valves, V-cylinder design for superior cooling, 2 year pump warranty
