Hyd-Mech V-18APC 18″ x 20″ Automatic Vertical Tilt Frame Band Saw

Name: Hyd-Mech V-18APC 18" x 20" Automatic Vertical Tilt Frame Band Saw
SKU: 129941
Price: 27500.00 USD
Availability: InStock

Stock #: 170240026

$27,500.00

See Product Details

Stock #: 170240026
Brand: Hyd-Mech

Not What You're Looking For?

Have Surplus Machinery to Sell?

Stock #: 170240026
Brand: Hyd-Mech

Request Formal Quote

Fill out the form below to receive a quote on this machine. Once the form is filled out, you will be able to see all pricing throughout our website.

Product Description

General Info

Stock #: 170240026
Location: Stone Mountain, GA
Brand: Hyd-Mech
Model: V-18APC
Approx. Shipping Weight: 8,000 Lbs.
Approx. Shipping Dimensions: 144″ L x 103″ W x 102″ H
Skidding Fee: Skidding Unavailable

Specifications

Cutting Capacity @ 90 Degree: 18″ x 20″
Cutting Capacity @ 45 Degree Left or Right: 13″
Blade: 1-1/4″ x 14’6″ x .042″
Blade Speed: 65 – 385 SFM
Blade Tension: Hydraulic
Blade Guides: Carbide
Wheel Diameter: 19″
Motors: 5HP Blade Drive, 2HP Hydraulic Drive
Vises: Hydraulic Full Stroke
Head Swing: Hydraulically Positioned and Locked. Full 45 Degree Left or Right
Table Height: 38″
Feed System: Hydraulic Variable Pressure, 0 – 300 PSI, Independent Feed Rate 0 – 15 IPM
Guide Arm: Hydraulically Positioned and Locked
Electrical: 460V/3PH

Equipped With

Hydraulic activated mechanical head brake, linear bearings on bar feed, high speed PLC encoder that monitors head angular position, several saw blades, manual
