Charmilles Robofil 440 CNC EDM Wire Cutting Machine
Stock #: 120230022
$17,500.00
Request Formal Quote
Fill out the form below to receive a quote on this machine. Once the form is filled out, you will be able to see all pricing throughout our website.
Product Description
General Info
- Stock #: 120230022
- Location: Stone Mountain, GA
- Brand: Charmilles
- Model: Robofil 440
- Serial #: 930477
- Year: 2004
- Approx. Shipping Weight: 7,500 Lbs.
- Approx. Shipping Dimensions: 17′ L x 8′ W x 8′ H
- Skidding Fee: Skidding Unavailable
Specifications
- Table Size: 35.43″ x 23.62″
- Maximum Work Piece Dimensions: 47.24″ x 27.55″ x 15.7″
- Maximum Work Piece Weight: 3,307 Lbs.
- Machining Stroke (X/Y/Z): 21.65″/13.78″/15.7″
- U/V Travel: 21.65″/13.77″
- Wire Diameters: 0.004″ – 0.012″
- Wire Spool Size: 17.7 Lbs.
- Degree Taper Cutting: 0 to 30 Degrees
- Dielectric Tank Capacity: 317 Gallons
- Electrical: 400V/3PH
Equipped With
Ebbco CLS-24 Chiller, Charmilles Dielectric Tank
Additional Info
The Charmilles EDM can be demoed upon request.
