Okamoto PSG-65UAN 24″ x 20″ Automatic 3-Axis Hydraulic Surface Grinder
Stock #: CD-220018
$14,500.00
Request Formal Quote
Fill out the form below to receive a quote on this machine. Once the form is filled out, you will be able to see all pricing throughout our website.
"*" indicates required fields
Product Description
General Info
- Stock #: CD-220018
- Location: Stone Mountain, GA
- Brand: Okamoto
- Model: PSG-65UAN
- Serial #: 332
- Approx. Shipping Weight: 7,000 Lbs.
- Approx. Shipping Dimensions: 9′ L x 7′ W x 7′ H
- Skidding Fee: Skidding Unavailable
Specifications
- Maximum Grinding Capacity: 24″ L x 19.7″ W
- Maximum Vertical Clearance: 21.6″ (With a 12″ Grinding Wheel Diameter)
- Maximum Permissible Weight of Work: 1555 Lbs.
- Maximum Table Travel (Manual): 29.5″ x 21.2″
- Table Working Surface: 25.6″ x 19.7″
- Longitudinal Hydraulic Feed Movement of Table: 1.0 – 83 Ft/Min.
- Hydraulic Cross Intermittent Feed: 0.02 – 0.8″
- Hydraulic Cross Continuous Feed: 4 – 40 IPM
- Cross Hand Feed Per Revolution: .25″
- Graduation of Cross Feed Handwheel: .001″
- Automatic Vertical Feed Per Table Stroke: .0001 – .0015″
- Automatic Vertical Feed Per Saddle Reversal: .0001 – .0015″
- Vertical Hand Feed Per Revolution: .05″
- Manual Vertical Micro-Feed: .0001 – .0015″
- Rapid Vertical Feed: .16/19″/min.
- Grinding Wheel Diameter x Width: 14/12″ x 1.5″
- Grinding Wheel Speed: 1800 RPM
- Grinding Wheel Spindle Motor: 5HP
- Hydraulic Pump Motor: 3HP
- Vertical Rapid Feeder Motor: 1/2HP
- Electrical: 230V/3PH
Equipped With
Kanetsu KET-5060-317B 23-5/8″ L x 19-5/8″ W Electro-Magnetic Chuck, Coolant / Dust System, Hydraulic Longitudinal & Cross Feed, Motorized Rapid & Automatic Incremental Down Feed, Operating Manual
Additional Info
The Okamoto 3-Axis Automatic Hydraulic Surface Grinder can be demoed upon request. Machine comes with our 30 Day MDNA Warranty.
