Haas EC-400-4AX 4-Axis CNC Horizontal Machining Center
Stock #: 120230087
$34,500.00
Request Formal Quote
Fill out the form below to receive a quote on this machine. Once the form is filled out, you will be able to see all pricing throughout our website.
Product Description
General Info
- Stock #: 120230087
- Location: Stone Mountain, GA
- Brand: Haas
- Model: EC-400-4AX
- Serial #: 51649
- Year: 2005
- Approx. Shipping Weight: 20,000 Lbs.
- Approx. Shipping Dimensions: 16′ L x 8′ W x 9′ H
Specifications
- Pallet Size: 15.75″ x 15.75″
- Machine Travels (X/Y/Z): 20″ x 20″ x 20″
- Pallet Indexing: Full 4th Axis (.001 Degree) Programmable
- Max Pallet Load: 660 Lb.
- Pallet Change Time: 8 Second
- Rapid Traverse Rate (X/Y/Z): 1000 IPM
- Max Cutting Feed Rate: 500 IPM
- Spindle Taper: CAT 40
- Spindle Speeds: 0 – 8000 RPM
- Toolchanger Capacity: 40
- Max Tool Weight: 12 LB.
- Tool to Tool Time: 2.8 Second
- Spindle Drive: 20 HP
- Tabletop to Spindle Center: 2.1″ – 22.1″
- Number of Pallets: 2
- Electrical: 230V/3PH
Equipped With
Haas CNC Control, Full 4th Axis Programmable, Automatic Pallet Changer, (2) Pallets, 300 PSI Thru-Spindle Coolant, 40-Station Side Mount Tool Changer, Floppy Drive, Renishaw Tool Presetter, Chip Auger, Remote Jog Handle, Coolant System
Additional Info
The Haas EC-400-4AX Horizontal Machining Center can be demoed upon request. Check out the video on the listing to see it in operation.
