Trumpf V130 CNC 7 Axis Hydraulic Press Brake w/ Trumpf Delem DA 24 CNC Control

Stock #: DD-B-200031

$34,500.00

Out of stock

  • Stock #: DD-B-200031
  • Brand:

Out of stock

  • Stock #: DD-B-200031
  • Brand:

Request Formal Quote

Fill out the form below to receive a quote on this machine. Once the form is filled out, you will be able to see all pricing throughout our website.

  • Hidden
  • Hidden
  • Hidden
  • Hidden
  • Hidden
  • This field is for validation purposes and should be left unchanged.

Product Description

General Info:

Stock #: DD-B-200031
Location: Lynnwood, WA
Brand: Trumpf
Model: V130
Serial #: 885023
Approx. Shipping Weight: 23,500 Lbs.
Approx. Shipping Dimensions: 144″ L x 87″ W x 94″ H

Specifications:

Capacity: 144 Tons
Overall Length of Bed & Ram: 120″
Distance Between Housings: 106″
Stroke: 8.5″
Open Height: 19″
Closed Height: 10.5″
Throat Clearance: 16″
Maximum Inclination of Ram: 0.4″
Approach Speed: 472″ Per Min
Form Speed: 2-24″ Per Min
Return Speed: 320″ Per Min
Distance Floor to Top of Bed: 34″
Width at Top of Bed: 4.75″
Operating Height: 4.75″
Hydraulic Reservoir Capacity: 66 Gallons
Main Motor Horsepower: 25
Voltage: 230/460/3/60

Equipped With:

Trumpf Delem DA 24 Controller, 4 Axis Back Gage (7-Axis Total) with Programmable Forming Speeds and Tonnage, I-Axis Die Shift, Electric Foot Switch / Palm Button Station, Hydraulic Upper & Lower Tool Holders and Full Rear Safety Enclosure

Additional Info:

This machine is being sold from our client’s facility and is sold AS-IS (Not covered under the MDNA Return Privilege). We always recommend machine be inspected in person to verify condition.
