This item has been sold

Search our inventory for a comparable solution

Haas DS-30SSY CNC Lathe (2011)

Name: Haas DS-30SSY CNC Lathe (2011)
SKU: 98518
Price: 89500.00 USD
Availability: OutOfStock

Stock #: CD-D-220014

$89,500.00

See Product Details

Out of stock

Stock #: CD-D-220014
Brand:

Not What You're Looking For?

Have Surplus Machinery to Sell?

Out of stock

Stock #: CD-D-220014
Brand:

Request Formal Quote

Fill out the form below to receive a quote on this machine. Once the form is filled out, you will be able to see all pricing throughout our website.

"*" indicates required fields

Comments

This field is for validation purposes and should be left unchanged.

First Name*

Last Name*

Company Name*

Phone*

Email*

Street Address

City

State

Zip

Message

This field is hidden when viewing the form

Post ID

This field is hidden when viewing the form

Quantity

This field is hidden when viewing the form

Product Name

This field is hidden when viewing the form

Product URL

This field is hidden when viewing the form

Product Price

Product Description

General Info

Stock #: CD-D-220014
Brand: Haas
Model: DS-30SSY
Year: 2011
Approx. Shipping Weight: 16,000 LBS
Approx. Shipping Dimensions: 190″ X 94″ X 96″

Specifications

Swing Over Front Apron: 31.75″
Swing Over Cross Slide: 20.75″
Distance Between Centers: 30″
X Axis Travel: 12.5″
Y Axis Travel: 4″
Z Axis Travel: 23″
Rapid Traverse Rate (Y and X): 472 IPM
Rapid Traverse Rate (Z): 1,200 IPM
Spindle Speed (Main and Sub): 4,800 RPM
Spindle Nose (Main and Sub): A2-6 / A2-5
Spindle Bore (Main and Sub): 3.5″ / 2.44″
Bar Capacity: 3.0″
Spindle Motor: 30 HP
Turret Capacity: 24 Stations
Live Tooling Speed: 6,000 RPM

Equipped With

Haas CNC Control, 24 Station Bot/Vdi Turret, 30 HP Main Spindle, 20 HP Sub Spindle, 10″ Chuck, 4500 Main & 4800 Sub Spindle, High Torque Live Tooling, C Axis On Both Spindles, Tool Presetter, Parts Catcher and Chip Conveyor

Additional Info

This machine is being sold from our client’s facility and is sold AS-IS (Not covered under the MDNA Return Privilege). We always recommend machine be inspected in person to verify condition.
